Optimizing for Output

Output Optimization
Preparing models for web and 3D printing

Different outputs need different preparations.

For Web (GLB)

Goals

  • Small file size
  • Fast loading
  • Good visual quality

Tips

  • Keep polygon count reasonable
  • Use simple materials (PBR)
  • Test in browser before deploying
  • Consider compression settings

Size Guidelines

  • Simple objects: < 500KB
  • Complex scenes: < 2MB
  • Try to stay under 5MB total

For 3D Printing (STL)

Requirements

  • Watertight mesh
  • Correct scale (usually mm)
  • No internal geometry
  • Minimum wall thickness

Checklist

  1. 1✅ Mesh is watertight
  2. 2✅ Scale matches real-world size
  3. 3✅ Walls are thick enough (>1mm)
  4. 4✅ No overhangs >45° (or plan supports)
  5. 5✅ Object sits flat on ground

Common Print Sizes

  • Most printers: ~20×20×20cm max
  • Check your printer's build volume
  • Design within constraints

Pre-Export Checklist

Before any export:

  1. 1Check from all angles

- Orbit around entire model
- Look for gaps or errors

  1. 2Verify dimensions

- Open Properties panel
- Confirm scale is as expected

  1. 3Test materials

- Colors look correct?
- Metalness/roughness appropriate?

  1. 4Clean up scene

- Hide helper objects
- Delete unused items
- Name objects clearly

File Naming

Use clear, descriptive names:

phone-stand-v2.glb
enclosure-final.stl
product-model-2024-01-15.glb

Include version or date for tracking!
