Bridging: Spanning the Gap 🌉

Bridging in 3D printing
How horizontal bridges work in 3D printing

A bridge is filament printed horizontally across a gap.

Bridge Length Limits

LengthResult
< 20mm✅ Usually perfect
20-50mm⚠️ Slight sag
> 50mm❌ Likely to fail

Improving Bridges

  • More cooling fan
  • Faster printing speed
  • Slightly lower temperature

Design Solutions

When you need a long bridge:

  1. 1Add support pillars

  2. 2Use an arch shape

  3. 3Design removable supports
